| Design Pressure |
12.5 MPa |
12.5 MPa |
12.5 MPa |
| Temperature Range |
20 - 250 ℃ |
20 - 300 ℃ |
20 - 300 ℃ |
| Type |
F-series flange reactor, K-series quick-opening reactor, Y-series one-touch quick-opening reactor |
F-series flange reactor, K-series quick-opening reactor, Y-series one-touch quick-opening reactor, Mechanical stirring, Magnetic stirring |
F-series flange reactor, K-series quick-opening reactor, Y-series one-touch quick-opening reactor, Mechanical stirring, Magnetic stirring |
| Material |
Inner: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy; Outer: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Inner: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy; Outer: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Inner: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy; Outer: Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Inner Material |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Outer Material |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Core Components |
Pressure transducer, axial pressure gauge, blast valve, air inlet, Exhaust valve |
Stirrer, Pressure gauge, Stirrer cooling water jacket, Exhaust valve, Safety blast valve, Air inlet valve, Thermocouple, Buffer pipe, Handle, Heating and insulation module, LCD screen and operation buttons, Control cabinet |
Stirrer, Pressure gauge, Stirrer cooling water jacket, Exhaust valve, Safety blast valve, Air inlet valve, Thermocouple, Buffer pipe, Handle, Heating and insulation module, LCD screen and operation buttons, Control cabinet |
| Design Standard |
Pressure vessels GB/T 150.1-150.4-2024 |
Pressure vessels GB/T 150.1-150.4-2024 |
Pressure vessels GB/T 150.1-150.4-2024 |
| Dimensions |
1150mm*450mm*750mm |
380mm*500mm*1100mm |
1430mm*650mm*750mm |
| Weight |
180 kg |
160 kg |
216 kg |
| Volume (M³) |
0.39 m³ |
0.21 m³ |
0.70 m³ |
