Horizontal electrophoresis cells for agarose gel electrophoresis, in two sizes: the LF-midiDNA (10101001) with gel trays up to 130x130 mm and up to 108 samples, and the compact LF-miniDNA (10102001) with 70 mm trays and up to 32 samples. Both are passive cells powered from an external electrophoresis power supply (not included). Per-model specifications are listed in the comparison table below.
Model Comparison
Specification
LF-midiDNA (10101001)
LF-miniDNA (10102001)
Catalog no.
10101001
10102001
Gel size
130x130 / 130x65 / 65x130 / 65x65 mm
70x70 / 70x100 mm
Combs
0.75 / 1.0 / 1.5 / 2.0 mm, up to 27 wells x 4 rows
0.75 / 1.0 / 1.5 mm, 9 / 16 wells
Max samples
108
32
Buffer volume
1000 mL
260 mL
Dimension
300x170x80 mm
260x110x80 mm
Weight
1.1 kg
0.6 kg
Package
38x22x18 cm, 3.0 kg gross
38x22x18 cm, 3.0 kg gross
Power
Passive cell - requires an external electrophoresis power supply (not included)
Passive cell - requires an external electrophoresis power supply (not included)
