| Design Pressure |
12.5 MPa |
12.5 MPa |
12.5 MPa |
| Temperature Range |
20-250℃ |
20 - 300 ℃ |
20 - 300 ℃; RT-600℃ customizable |
| Material |
316L (inner/outer); customizable |
— |
Standard Material: 316L (inner and outer); customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Inner Material |
316L |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Outer Material |
316L |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
Standard Material: 316L, customizable materials include Hastelloy, Monel alloy, and Inco nickel alloy |
| Model No. |
HT-50KC-1P3T3S6B-4-PX(B) |
— |
— |
| Stirring Method |
Magnetic Stirring |
— |
— |
| Reactor Volume |
0.39 m³ |
— |
— |
| Customizable Materials |
Hastelloy, Monel alloy, Inco nickel, Titanium, Zirconium |
— |
— |
| Stirring Motor Power |
40W/400W (customizable) |
— |
— |
| Type |
— |
F-series flange reactor, K-series quick-opening reactor, Y-series one-touch quick-opening reactor, Mechanical stirring, Magnetic stirring |
F-series flange reactor, K-series quick-opening reactor, Y-series one-touch quick-opening reactor, Mechanical stirring, Magnetic stirring |
| Core Components |
— |
Stirrer, Pressure gauge, Stirrer cooling water jacket, Exhaust valve, Safety blast valve, Air inlet valve, Thermocouple, Buffer pipe, Handle, Heating and insulation module, LCD screen and operation buttons, Control cabinet |
Stirrer, Pressure gauge, Stirrer cooling water jacket, Exhaust valve, Safety blast valve, Air inlet valve, Thermocouple, Buffer pipe, Handle, Heating and insulation module, LCD screen and operation buttons, Control cabinet |
| Design Standard |
— |
Pressure vessels GB/T 150.1-150.4-2024 |
Pressure vessels GB/T 150.1-150.4-2024 |
| Dimensions |
— |
380mm*500mm*1100mm |
1430mm*650mm*750mm |
| Weight |
— |
160 kg |
216 kg |
| Volume (M³) |
— |
0.21 m³ |
0.70 m³ |
